Vintage Computing: Computers, Components and Electronics

Vintage Products

Vintage Computers and Electronics

Vintage computers and electronics are something that we have actively collected for many years. We sometimes purchase a collection of technology as we see the value in some items and want to see it go back into the experimenter, collector, and hobbyist communities.

This is a listing of computer systems, accessories, and electronic components which we have saved which are all looking for new homes.

All of the equipment is older technologies and generally untested (unless where noted). We do our very best to show accurate photographs of the equipment and provide descriptions where possible.

Looking for new components and accessories? Be sure to visit the PCBoard.ca site where we have everything from Capacitors, Resistors, Connectors, LEDs, and much more.

Shipping and Pickup

Several items we have are not available to be shipped. This is due to the fact the item may be too large or fragile. Items not available for shipping will be noted in the product description. For these items, local pick-up is available in Mississauga, Ontario.

Shipping: We use Canada Post for shipping. Rates vary by location along with package size and weight. Contact Us listing your Mailing Address along with the items of interested and we can provide a quote on shipping.

Local Pickup: Picking up your order is an option. Contactless pickups are available in Mississauga, Ontario, Canada by appointment.

Pricing

Prices listed are in US$. For clients in Canada, we will use current bank exchange rates for payment in Canadian funds which can be made using PayPal or alternately Interac.

Local pickup is available from Mississauga, Ontario, Canada and payments can be made at time of pickup by Cash in Canadian funds.

Interested in More Information?

If you have interest in any of the items listed, use our Contact Form where you can request additional information, shipping rates, or product details.

We also have a good article on TRS-80 Model 4 Easy Power Supply Refurbishing. Watch for more articles on restoring and maintain your vintage TRS-80 systems.

TRS-80 Accessories

Bartlett Labs - MISE - Model I System Expander

MISE Model I System Expander for TRS-80 Model 1 - Image 3 of 3

click images to expand view

Bartlett Labs – MISE – Model I System Expander – $150.00 US –  1 Available

The Bartlett Labs MISE (Model I System Expander) is an add-on device for the vintage Radio Shack TRS-80 Model I microcomputer. It connects to the buffered expansion port on the Expansion Interface or directly to the Model I keyboard.

Features and Benefits:

  • Direct-booting solid state hard disks on Compact Flash, with LDOS-5.3.1 preloaded. No boot floppy or ROM modification is required. Each bootable image can hold up to 64MB, and multiple images on CF cards are supported. That’s a whole lot of space for programs mostly written for 16KB RAM. Dual CF cards can be used for additional storage or easy backup.
  • 10/100 Mbps wired Ethernet connection (up to 8 active IP sockets) with included software: FTP and TFTP servers, FTP client, DHCP client, SNTP client, Telnet client, and Telnet server and DNS client demo programs. Globally-unique MAC address (EUI) provided. Easily move files to and from your TRS-80! Drag and drop!
  • Real-time clock/calendar with battery backup, compatible with the vintage Alpha Products Newclock-80. Battery backup means the date and time will be accurate and automatically set at every system boot.
  • Crystal-clear SVGA display output for an 800×600 @ 60Hz monitor, no software required. One-of-eight selectable foreground, background, and border colors. Emulation of the vintage high-resolution PCG-80 and 80-Grafix devices. 80-column text display mode available. Using the VGA display is optional; you can still use the original CRT monitor if you prefer, or you can even use both at the same time.
  • ROM extension including drivers for the hard disks, real-time-clock, and double-density floppy adapter, if you have one. None of these drivers need consume precious high memory.
  • Joystick port for Atari 2600 compatible joysticks. Works with most vintage Model I games.
  • 256-byte general-purpose Flash EEPROM for persistent storage.
  • Unit includes two preinstalled Compact Flash cards, one 2GB, the other 8GB

For more information, documentation, and associated files, see the Bartlett Labs support site.

I am not able to test or confirm the functionality of this board, so it is being sold as-is. I was assured this was fully working when it was last used in April of 2021.

This item can be shipped. Contact Us for shipping costs.
Product: 26x26x12x550
Shipping USA: $26 (Tracked Packet)

SOLD Items - Listings For Reference Only

Bartlett Labs - MIRE - Model I Replacement Expansion Interface

Bartlett Labs - MIRE TRS-80 Model I Expansion Interface - 03

click images to expand view

Bartlett Labs – MIRE – Model I Replacement Expansion Interface – $150.00 US Sold

The Bartlett Labs MIRE is a modern replacement for the TRS-80 Model I Expansion Interface. It connects to the expansion port on the left rear of the Model I keyboard.

Features and Benefits:

  • 32KB SRAM, expanding your system to a full 48KB. The additional RAM can be disabled for those with RAM upgrades already within the keyboard unit.
  • Single/double density, single/double-sided floppy controller, compatible with the original doublers from Radio Shack and Percom/Aerocomp.
  • Emulated floppies on Secure Digital (SD). Includes a full-featured TRS-80 application for manipulating files and mounting DMK files as floppies. Floppies and files can also be controlled from a PC using an SD card reader/writer. Included SD card has bootable LDOS installed, but MIRE also works with other DOSes (NewDOS, MultiDOS, TRS-DOS, etc.)
  • RS-232 on a 9-pin D-SUB connector, compatible with the original Model I RS-232 expansion board from Radio Shack. Includes a 64-byte receive FIFO to help prevent overruns.
  • Line printer port on a DB-25 connector, compatible with the original expansion interface.
  • Cassette sound output on a 3.5mm jack. Includes RC filtering to improve sound quality.
  • Expansion port for connecting your MISE or vintage peripherals.
  • Heartbeat interrupt for maintaining DOS software clocks
  • Unit comes with a 16GB SD Card


For more information, documentation, and associated files, see the Bartlett Labs support site.

I am not able to test or confirm the functionality of this board, so it is being sold as-is. I was assured this was fully working when it was last used in April of 2021.

This item can be shipped. Contact Us for shipping costs.
Product: 26x26x12x550
Shipping USA: $26 (Tracked Packet)

The Bartlett Labs MISE and MIRE can be purchased as a set for $275.

Lo-tech TRS-80 IDE Adapter

click images to expand view

Lo-Tech TRS-80 IDE Adapter – $40.00 US Sold

This is the Lo-Tech TRS-80 IDE interface for use with a TRS-80 Model III, 4, 4P, or 4D. The board is fully assembled and tested and is capable of being used as a boot device. The board also includes the PQI Industrial 128mb DOM.

The board does require external power through the onboard USB port (the USB power source is not included with this unit). You will also require a 50-Pin expansion cable (see here).

These units were tested on a auto-booting TRS-80 Model 4P and all boot into the onboard IDE drive which has LDOS preinstalled.

More information on the boards is available from here and here.

There is also a great FAQ document that provides more technical information, parts list, software sources, and more from here.

This item can be shipped. Contact Us for shipping costs. 1 Unit remaining
Product: 11x9x5x100

Kaypro II System

click images to expand view

Kaypro II Luggable CP/M Machine – $140.00 US –  Sold

Kaypro II system. Unit is clean and in really good shape. Was able to power up the unit, and received the insert disk notification. Unit is complete with keyboard, but is missing the keyboard (RJ11?) cable, so I was not able to do any testing beyond a brief power-up.

Machine has two floppy drives, and a couple of manuals.

This item cannot be shipped.

Local pickup is available in Mississauga, Ontario. Contact Us for any questions.

TRS-80 4P

click images to expand view

TRS-80 4P System – $225.00 CDN   Sold

TRS-80 Model 4P. The system is in good condition, would rate a 7-10.

Unit powers up and boots from the included Lo-tech TRS-80 IDE Adapter which has a 128MB drive installed on it. The drive is pre-loaded with LDOS and boots up to the LDOS prompt.

Case and keyboard are in good condition, slight discoloration for its age, with the keyboard having all keys and functions.

There are two 5.25″ drives installed, LDOS reports each as being 40 cylinder double-density, one being a single-sided drive, the other as double-sided.

The back of the unit shows an internal modem card installed.

The screen is a white phosphor model and is a bit dim. The screen also “shimmies” during floppy drive access which is an indication the integrated power supply is a candidate for re-capping.

Lo-tech TRS-80 IDE Adapter Boards & Components

click images to expand view

Lo-tech TRS-80 IDE Adapter Parts Kit – $35.00 US   Sold

Kit of parts to build up your own Lo-tech TRS-80 IDE rev. 2 interface. Includes 5 new blank PC board, several connectors including the USB thru-hole connectors along with various resistors and capacitors. This is not a complete kit as the IC’s are missing and possibly some other components.

This is a package that includes five blank PC boards.

More information on the boards is available from here and here.

There is also a great FAQ document that provides more technical information, parts list, software sources, and more from here.

Product: 24x18x5x270

MAPPA-1 CP/M Card for Model I

click images to expand view

MAPPA-1 CP/M Card for TRS-80 Model 1 – $40.00 US –> Sold

This is a reproduction from Ian Maverick of the MAPPA-1 to allow the TRS-80 Model 1 to run CP/M.

Units appear to be new, never used. See http://ianmav.customer.netspace.net.au/cpm/ for additional product information, software downloads, installation instructions. I also have a CP/M boot disk for each of the boards.

Product: 19x19x7x100

TMS4116 16Kx1 RAM

click images to expand view

TMS4116 16Kx1 RAM – Tube of 25-Pieces – $50.00 US –> Sold

Available 8 tubes of 25 pieces of TMS4116 RAM. Appear to be NOS (new old stock). I have tested 16 pieces without any issues. Pins scratch-free and appear to have never been used. Will only be sold in tubes of 25 pieces.

This item can be shipped. Contact Us for shipping costs. 8 tubes of 25 pieces available.
Product: 25x4x4x100
